Product Description

Klipsch R-600F Floorstanding Speaker (Pair)

LINEAR TRAVEL SUSPENSION (LTS) ALUMINUM TWEETER WITH KAPTON SUSPENSION
The exclusive Linear Travel Suspension (LTS) minimizes distortion for enhanced, detailed performances. Aluminum is an extremely light and rigid material used in the tweeter assembly to provide high efficiency and improve resolution and detail. LTS tweeters are a hallmark of Klipsch speakers, making it a core component of some of the best speakers in the world.

SPUN-COPPER THERMOFORMED CRYSTALLINE POLYMER (TCP) WOOFERS
Utilizing trickle-down technology from Klipsch’s highly-acclaimed Reference Premiere series, the TCP woofers have steeper angling of the cones for a smoother response and improved accuracy and transparency. The additional ribbing increases the overall rigidity for less cone breakup at higher frequencies.

REAR TRACTRIX PORT
The rear Tractrix port is perfectly matched to the cabinet and woofers, creating ideal airflow with minimal distortion or turbulence even at the lowest frequencies.

SLEEK, MODERN APPEARANCE
Hidden fasteners, edge-to-edge horn, and low-profile magnetic grilles give the speakers a polished, modern appearance.

MDF CABINET WITH SCRATCH-RESISTANT, TEXTURED WOOD GRAIN VINYL
Stylish aesthetic with absolute durability that results in a seamless integration into any décor.

HIGH-QUALITY CABINET DESIGN
Reinforced 3/4” MDF construction with an all-new bracing design reduces cabinet vibration for less audible coloration and improved sonic accuracy.

REFINED ATMOS CONNECTIONS
Upgrading to Dolby Atmos is extremely easy with the simple and hidden connections located on the back of the speakers. These refined connections reduce the amount of wire seen and hold them in place for better wire management.

Denon DRA-800H 2ch Hi-Fi Network Receiver (Each)

High-Performance Discrete 2-Channel Amplifier

The DRA-800H Hi-Fi network receiver amplifier is specifically designed to meet the needs of your two-channel system. Featuring a custom discrete high-current power amplifier, symmetrical design and an OFC (oxygen-free copper) winding power transformer, the DRA-800H delivers maximum performance and 100W of power per channel (8 ohm, 20Hz – 20kHz, THD: 0,08%, 2ch Driven). With low impedance drive capability, it offers greater stability with a wide range of floor-standing and bookshelf loudspeakers for balanced, quality sound, every time. Auto ECO mode helps reduce power consumption, without sacrificing audio quality.

EXPERT SOUND ENGINEERING

Denon sound engineers use carefully selected Hi-Fi parts, including custom resistors and audio grade capacitors, to tune the stereo receiver. Using the design principles found in Denon award-winning amplifiers, the DRA-800H features a symmetrical layout, double differential DAC circuit and analog preamp circuits that don’t interfere with the power supply. The dedicated circuitry with its short, straight paths between the power supply, signal and amplification ensure your loudspeakers drive detailed and precise imaging.

MUSIC STREAMING

Enjoy a wide array of music streaming service including spotify free and premium, deezer, tidal, amazon music and many more. Explore the world of internet radio with tunein and enjoy distortion free radio from all over the globe.

HIGH-RESOLUTION AUDIO

Enjoy superb audio fidelity with your favourite high-resolution audio tracks. The DRA-800H with AKM 32-bit D/A converters features high-resolution audio decoding with multiple lossless file types, including ALAC, FLAC and WAV at up to 24-bit/196-kHz. It’s also compatible with 2.8/5.6-MHz DSD files (DSD is the audio coding format of SACD). Play them from memory devices via the front panel USB, or over network sources. The DRA-800H also supports other file types such as MP3 and WMA.

SPEAKER A/B AND ZONE 2 PRE-OUT

Connect two pairs of speakers for easy A/B switching. Or, extend your system to a second room and listen to a different source in Zone 2 via pre-outs.

PHONO INPUT FOR TURNTABLE/VINYL SUPPORT

For nearly 50 years, Denon has been developing turntables, cartridges and phono pre-amps. With the included phono input, the DRA-800H lets you connect your turntable and play vinyl records. Enjoy your collection with exceptional quality and sound.

DUAL DAC DIFFERENTIAL CIRCUIT

The DRA-800H utilizes an eight-channel premium DAC to deliver amazing stereo imaging and detail. By assigning two DAC’s per channel including the subwoofer output, hear increased dynamic range and improved signal to noise (s/n).

ADVANCED HDMI VIDEO SECTION

Enjoy your favourite movies, shows and games with the best picture quality available.

ADVANCED HDMI VIDEO SECTION WITH ARC

The DRA-800H features 5 HDMI inputs and 1 output — that support full 4K Ultra HD 60Hz video, 4:4:4 Pure Color sub sampling, High Dynamic Range (HDR10), Hybrid Log-Gamma (HLG), ARC, 3D, and BT.2020 pass-through support for exceptional colour, clarity and contrast. Audio Return Channel (ARC) support enables the transmission of audio directly from the smart TV to the receiver through the connected HDMI cable.

ADVANCED VIDEO CONTROLS

HDCP 2.3 processing is available on all HDMI ports, letting you enjoy copy-protected content totally uninhibited. Enjoy seamless compatibility with the latest HD and Ultra HD TVs, Blu-ray players and game consoles.

EASY SETUP EXPERIENCE

The included DRA-800H Quick Start Guide provides simple, clear instructions for how to get started. Once you connect your TV to the DRA-800H via HDMI, the exclusive Denon Setup Assistant appears on your TV screen to walk you through setup, step-by-step.

BUILT-IN BLUETOOTH AND WI-FI CONNECTIVITY

The heart of your wireless network. For Bluetooth, Wi-Fi and AirPlay 2 wireless streaming connectivity, the Denon DRA-800H is equipped with an advanced dual antenna transceiver system for robust streaming even in congested urban environments. Enjoy listening to your favourite audio content wirelessly from your smart devices.

With HEOS Built-in technology play the same song in every room or select a different song for each connected room — the choice is yours. HEOS works with Amazon Alexa and Google Assistant, providing effortless voice control.

HEOS supports free and premium Spotify, Amazon Music, Deezer, TuneIn, Sound Cloud, Tidal and more.

QUICK SELECTS FOR USER-FRIENDLY AUDIO TUNING

The Denon DRA-800H front panel features four Quick Select buttons that store your preferred audio settings for each source. Switch between TV audio, Blu-ray, media players and more, and the DRA-800H adjusts the EQ settings to your preferences for that media source. Use the buttons on the front panel or opt for the same Quick Select on the receiver remote for faster control. Now allows for one-push all zone stereo mode via Quick Select.

AUTO LOW LATENCY MODE

Auto Low Latency Mode (ALLM) ensures Xbox One users have a more responsive and immersive gaming experience when connected with select TV models that also support ALLM.

WORKS WITH LATEST VOICE ASSISTANTS

Enjoy effortless voice control and total flexibility from the leading voice services. Using a smart speaker or your phone, speak commands with Amazon Alexa, Google Assistant, Apple Siri. Ask to play your favourite music, turn the volume up, skip to the next track, switch inputs and more. Switch between voice services or pick a favourite to use — the choice is yours. Functionality varies by voice agent.

WORKS WITH AMAZON ALEXA

Control the DRA-800H hands-free with Amazon Alexa and your voice. Adjust the volume, skip to the next track, switch inputs for your different media players and more — “Just Ask.” Download the free HEOS Home Entertainment Skill to enable Amazon Alexa voice commands for your DRA-800H, HEOS devices and other Denon products with HEOS built-in. Requires Alexa app and Amazon Echo, Dot or equivalent.

WORKS WITH GOOGLE ASSISTANT

Start music in the HEOS app, then ask your Google Assistant to control volume, play, pause, skip tracks and more.

AIRPLAY 2 + APPLE SIRI VOICE CONTROL

Use AirPlay 2 to stream music wirelessly to the AV receiver, or group with other AirPlay compatible speakers to fill your home with music.

Stream audio from your favourite music services like Apple Music and Spotify or watch videos from services like YouTube and Netflix from any iPhone, iPad, Mac or Apple TV and hear the audio perfectly synced to your speakers AirPlay 2 sources.

HEOS BUILT-IN FOR

WIRELESS MUSIC STREAMING

Stream your favourite music from anywhere and everywhere around your home with HEOS Built-in technology. Enjoy high quality music from a wide range of streaming services including Spotify®, TuneIn, Amazon Prime Music, Soundcloud®, Tidal, Napster, Deezer or local music sources. Control it all seamlessly with the free HEOS app.

CUSTOM INSTALL READY

The Denon DRA-800H features external control and IP control capabilities for easy customization and compatibility with third-party integration solutions. It offers IP control capability for major third-party control devices, as well as Control4 SDPP (Simple Device Detection Protocol) certification for seamless integration with Control4 home automation equipment. An IR (infrared) remote control jack is on the rear panel for remote control compatibility with other components in your home theatre system.

100+ YEARS OF FIRSTS IN AUDIO TECHNOLOGY

Founded in 1910, Denon has a deep heritage of “firsts” in audio technology — from Japan’s first audio electronics manufacturer, to producing the world’s first commercial CD player and Dolby Atmos-enabled AV receiver. This focused investment in audio R&D ensures you get the latest technology and highest quality with every listening experience.

PRODUCT HIGHLIGHTS:

• 100 watts x 2 into 8 ohms (20-20,000 Hz) at 0.08% THD
• built-in dual-band Wi-Fi for music streaming over your wireless home network
• built-in Bluetooth for wirelessly streaming audio from compatible smartphones, tablets, and computers
• Apple® AirPlay® 2 for streaming music from an iPhone® or iPad®
• Bluetooth transmitter mode for wireless streaming to compatible headphones and speakers (via future firmware update)
• front-panel USB input for playing music from USB memory device
• plays high-resolution digital music files via USB storage device or a networked computer (PCM up to 24-bit/192kHz resolution; DSD up to 5.6 MHz)
• compatible with Amazon Alexa, Google Home, Siri and Josh.ai for hands-free voice control
• built-in HEOS technology for wireless whole-home audio

CONNECTIONS:

• HDMI 2.0a audio/video switching: 5 in, 1 out
• HDCP 2.3 technology ensures compatibility with 4K Ultra HD sources and TVs
• HDR-compatible for extended picture contrast and brightness with compatible 4K TVs and HDR-encoded content
• supports HDR 10 and HLG (Dolby Vision™ not supported)
• ARC (Audio Return Channel) receives digital audio signals from the TV’s tuner or “smart” content via HDMI
• 2 optical digital inputs
• 1 coaxial digital input
• 2 stereo RCA inputs
• dedicated phono input lets you connect your turntable to the receiver
• dual mono preamp outputs for connecting powered subwoofers
• Ethernet port for wired network connection
• front-panel Type-A USB input
• line-level stereo RCA output for a second zone
• full-size 1/4″ headphone jack on the front panel

DIMENSIONS

• 17-3/16″W x 8-1/2″H x 14-3/16″D (with antennas raised)
• weight: 18.3 lbs.
