- 2 channels
- 160 watts per channel
- MM/MC phono stage
- Ultra AL32 Processing
- Optical, coaxial, and USB digital connections
- Pure Analog mode
With an advanced push-pull amplifier, sophisticated digital processing, and a robust phono stage, the PMA-3000NE delivers all of your favorite music with clarity and precision.
Drives even the most demanding speakers
A push-pull amplifier, delivering 80W/channel into 8 ohms and 160W/channel into 4 ohms, effortlessly accommodates a range of speaker types and impedances.
Seamlessly integrate high-resolution digital audio
Digital connections, including optical, coaxial, and USB-B, support up to 384kHz/32- bit. Ultra AL32 Processing waveform interpolation produces smooth, high-resolution sound.
Unlock your vinyl collection’s full potential
The PMA-3000NE’s phono stage supports both MM and MC cartridges, for the most faithful sonic reproduction regardless of cartridge type.
Specifications
Performance
-
Rated Output Power:
- 80W + 80W (8Ω, 20 Hz – 20 kHz, THD 0.07%)
- 160W + 160W (4Ω, 1 kHz, THD 0.7%)
-
Total Harmonic Distortion (THD):
- 0.01% (Rated output: –3 dB, 8Ω, 1 kHz)
Input Sensitivity & Impedance
-
Phono Input:
- MM: 2.5 mV / 47 kΩ
- MC: 200 μV / 100 Ω
- CD/Line/Recorder: 135 mV / 19 kΩ
- Power Amp Input (EXT. PRE): 0.9 V / 47 kΩ
Signal-to-Noise Ratio (SNR)
- Phono MM: 89 dB
- Phono MC: 74 dB
- CD: 107 dB
Power Consumption
- Normal Operation: 400 W
-
Standby:
- 0.2 W (TV Autoplay Off)
- 0.4 W (TV Autoplay On)
Audio Features
- Power Amplifier Circuit: New UHC-MOS Single Push Pull (7)
- Preamplifier Circuit: Variable Gain Preamplifier (OP AMP)
-
Tone & Balance Control:
- Bass: Yes
- Treble: Yes
- Mid: No
- Balance: Yes
- Source Direct: Yes
- Analog Amp Mode: Yes (Button on front panel)
Digital Features
- DAC Circuit: ES9018K2M × 4
- Digital Processing: Ultra AL32 Processing
- DAC Master Clock Design: Yes
- Asynchronous Mode (USB-B): Yes
General Details
-
Dimensions (W × H × D):
- 434 × 182 × 443 mm
- Net Weight: 24.6 kg
