ABSOLUTE CONNECTIVITY.
Phantom II Custom boasts professional features such as Dante™ network and analog/AES input, is fully compliant with technical integrator requirements, and is simply configurable through IP address webpages.
BESPOKE CONTROL.
Phantom II Custom is designed to be operated by third-party devices such as preamps, professional audio DSP, and matrix mixers. It also lets you control your sound system from your network infrastructure via Savant, Control4, Crestron, or drivers.
FITS INTO ANY ENVIRONMENT, RELIABLY.
Among available solutions, Devialet chose Audinate's Dante™ network for its reliability in audio streaming on an ethernet network infrastructure. Dante™ helps Phantom II Custom** fit seamlessly into any existing setup, allowing up to 256 channels of HD audio to be streamed over standard ethernet cables.
_________________________________________________
Loudspeakers
1 x Aluminum Full-Range driver2 x Aluminum Bass driversDigital to Analog Converter
Devialet DAC embedded in Devialet Intelligence Processor24bits / 96kHzTHD: -112dBProcessor
ARM Cortex-A9 1.25GHz processor 512MB DDR3-195 dB memorySide Plating
Body: white RAL 9016 | White matte stainless steel sidesPower Supply
IEC 100-240V ~ 50/60HzDimension
Width: 157 mm | Height: 168 mm | Depth: 219 mmWeight
4.3 kgMaximum Sound Level
96 dB SPL at 1 meterTotal amplification power
375 Watts RMSAmplification Performance
THD+N* : 0.001% | Saturation : 0 | Background Noise 0 dB SPL at 1m (*Total Harmonic Distortion + Noise)Frequency response (bandwidth)
Bandwidth: 18Hz to 21kHz (@-6dB)Accuracy in frequency response: ± 1dB from 25Hz to 20kHzSynchronisation
Admin webpage through EthernetUnlimited amount of devicesConnectivity
Network: Ethernet, Dante support Inputs: Euroblock connector, configurable in- AES/EBU 110 Ohms balanced digital input- balanced analog mono inputIP control (Crestron, Control4)Network
Ethernet RJ-45 10/100/1000 Mbps (Gigabit) Dual network interface, Dante audio streaming, and IP controlVia an online configuration page (// ip_address), accessible via the IP address of your Phantom II Custom on the web browser of your choice. You can then select your inputs and make your adjustments.
Yes, Phantom II Custom has an IEC universal power supply (90-240 V ~ 50 / 60Hz).
Yes, Phantom II Custom is IP44 certified. It is protected against splashing water from all directions.
