Projector Specs:
|
Model Information |
|
|
Series |
L5 |
|
Internal Model |
120L5HE |
|
Retail Model |
120L5H |
|
PRD Address |
http://10.18.203.58:8000/svn/doc/DevProjiectMNG/MT9900/MT9900_Vidaa_EUEM/01-Software/01-Start/tags/02-PRD/LaserTV_Special_PRD |
|
Built-in Video SVN |
http://10.18.203.58:8000/svn/Video_Epos/DevProjiectMNG/MT9900/MT9900_Vidaa_EUEM/01-Software/01-Start/trunk/08-StoreModeMaterial/Build_in-Video/LaserTV/L5HE/Laser_TV_L5.mp4 |
|
EPOS SVN |
http://10.18.203.58:8000/svn/Video_Epos/DevProjiectMNG/MT9900/MT9900_Vidaa_EUEM/01-Software/01-Start/trunk/08-StoreModeMaterial/EPOS/LaserTV/L5HE/L5HE.rar |
|
Online Model |
NA |
|
Basic Information |
|
|
ID Color |
Silver, Gray |
|
Resolution |
4K |
|
Aspect Ratio |
16:9 |
|
Display Technology |
DLP |
|
Light Source |
Laser Source |
|
DMD |
0.47” |
|
Throw Ratio |
0,25 |
|
Audible Noise |
32dB |
|
Display Surface |
Flat |
|
Digital geometric or keystone correction |
Yes,Both Auto and Manual correction |
|
Lens shift |
No |
|
Focus |
No |
|
Zoom (Optical or Digital) |
No |
|
Lens cover |
No |
|
Light source lifetime |
25,000 hours (Luminance drop 50%) |
|
Eye Protection (Automaitic turn off laser when people close by) |
Yes |
|
Resistant (IP Level) |
NA |
|
Kensington Security Slot |
Yes |
|
RoHS Compliant |
Yes |
|
Recyclable Product |
Yes |
|
Speakers / Type |
builtin |
|
Audio Power Output |
No |
|
Screen Size (Class) |
120 |
|
Screen |
120" |
|
Screen Type |
Fresnel Lens Technology&Black/White Lenticular Technology |
|
Category |
4K Smart Laser TV |
|
UI |
VIDAA U6 |
|
Technical Details |
|
|
Luminance (Peak, full field, in Lumens) |
2700lm |
|
Static Contrast |
>3000：1 （具体基于样机实测数据） |
|
Dynamic Contrast Ratio |
2000,000：1 |
|
Number of Colors |
1.07B |
|
Resolution |
3840*2160 |
|
4K Upscaling |
Yes |
|
10 bit Colorimetry |
Yes |
|
HDR Compatible |
Yes |
|
HDR10 |
Yes |
|
HLG |
Yes |
|
HDR10+ decoding |
Yes |
|
Dolby Vision |
Yes |
|
HDMI-ARC Support |
Yes |
|
HDMI-CEC Support |
Yes |
|
MHL Support |
No |
|
Anyview Cast (Miracast) |
Yes |
|
Network Streaming (DLNA) |
Yes |
|
Wireless Digital Audio (Bluetooth) |
Yes |
|
Wide Color Gamut |
No |
|
NTSC1931 |
80%±5%NTSC typical |
|
3D |
No |
|
Processor |
MT9900 |
|
Upscaling Ultra HD |
Yes |
|
MEMC |
Yes |
|
Frame rate |
60Hz |
|
Motion rate |
120 |
|
Decoder |
HEVC (H.265),VP9,H.264,MPEG4, MPEG2,VC1,MVC |
|
Input Lag in Game Mode |
≤60ms |
|
3D Digital Comb Filter |
Yes |
|
MPEG noise reduction |
Yes |
|
Mosquito noise reduction |
Yes |
|
Sound |
|
|
Sound output power |
2×20W |
|
Sound Technology |
Dolby Atmos |
|
NICAM / A2 Stereo |
NICAM Stereo |
|
User Equalizer |
Yes (Advanced Parametric Equalizer,the compensation of frequency characteristics based on input signal level to fit the acoustic characteristics of human ears) |
|
Sound - Special |
Dolby Audio(MS12) Dolby Atmos |
|
AC-4 |
Yes |
|
MPEG-H |
No |
|
Convenience |
|
|
Media Player |
Yes (Video, Audio, Picture) |
|
Multi-Language OSD |
English Français Deutsch Italiano Español Português Svenska Dansk Suomi Norsk Čeština Slovenčina Polski Magyar Български Türkçe 中文 Русский O'zbekiston العربية हिंदी Arabic Hindi Latvija Eesti Lietuva |
|
Hotel TV |
Yes |
|
User Interface |
VIDAA U6 |
|
Internet |
|
|
Important Apps (all countries) |
Netflix, YouTube, Prime Video (Amazon) |
|
Country-specific apps |
Freeview Play (UK), Maxdome (GER), Timvision(IT),ChiliTV(IT),BBC iPlayer(UK),Mitele(SPAIN),RTVe(SPAIN),IVI(RUS),OKKO(RUS),MEGOGO(UKR),Rutube(RUS),Channel One(RUS);Rai Play(IT);RMC (SFR sports)(FRANCE),OLL TV(UKR),Divan.TV(UKR),CDA.PL(POL) |
|
Web browser |
Odin |
|
HbbTV |
V2.0.2 |
|
MHEG support |
Yes,(but only if Certification requires,e.g. Ziggo) |
|
Anyview Cast |
Yes |
|
Anyview Stream |
Yes (DMP,DMR) |
|
Smartphone app |
VIDAAAPP |
|
Reception and TV Features |
|
|
Digital and Analog Tuner |
DVB-T2/T/C/S2/S |
|
Twintuner |
No |
|
LCN Support |
Yes (Depending on location and operator) |
|
Teletext Support |
Yes |
|
EPG |
7 days forward EPG, 7 days backwards EPG (UK Only) |
|
Parental Control |
Yes |
|
PVR |
Yes |
|
Time Shift |
Yes |
|
Channel sorting |
Build-in and exportable for PC edit (ChSort) |
|
Favorite channel list |
4 |
|
Connectivity |
|
|
Common Interface (CI+) |
Yes(V1.4) |
|
HDMI1 |
HDMI2.1(ALLM) |
|
HDMI2 |
HDMI2.1(ALLM,eARC) |
|
HDMI3 |
HDMI2.0 |
|
USB (2.0) |
1 |
|
USB (3.0) |
1 |
|
S/PDIF Output |
1 (optical) |
|
RCA L/R Output (Analog) |
0 |
|
Headphone Output |
1 |
|
RF Tuner |
2 |
|
Composite (AV) Input |
0 |
|
Component YPb(Cb)/Pr(Cr) Input |
NA |
|
SCART |
NA |
|
VGA Input |
0 |
|
VGA L/R Audio(mini jack) |
0 |
|
Audio (L/R) Input |
0 |
|
Subwoofer |
NA |
|
Ethernet RJ45 port |
Yes |
|
Wireless LAN adapter Support |
Yes |
|
WiFi technolegy |
802.11ac, dual-band (2.4G and 5G) |
|
Bluetooth Support and profiles |
A2DP & AVRCP |
|
light sensor |
No |
|
RS232 |
No |
|
service port |
1 |
|
Eco & Power supply |
|
|
Power Supply |
120V-240V |
|
Energy Efficiency Class |
NA |
|
Standby Consumption |
≤0.5W |
|
Power off |
NA |
|
Power Consumption (Nameplate) |
350W |
|
Annual consumption (Nameplate) |
NA |
|
Power Consumption (Energy Rating Label) |
NA |
|
Annual consumption (Energy Rating Label) |
NA |
|
Luminance Ratio |
NA |
|
Mercury content |
0 mg |
|
Lead content |
Yes -This television contains lead only in certain parts or components,in accordance with existing exemption clauses under the RoHS Directive. |
|
Weight & Dimensions |
|
|
Weight incl. Packaging |
12.6kg |
|
Product weight incl. Stand |
TBD |
|
Product weight excl. Stand |
9.4kg |
|
Weight of carton box |
2.2kg |
|
Weight of plastic foam in package material |
TBD |
|
Weight of plastic in package material |
TBD |
|
Weight of metal in package material |
TBD |
|
Package (Horizontal/Vertical) |
TBD |
|
Packaging Dimension (LxDxH) |
565.6 ×319.7×121.2mm |
|
Product Dimension (LxDxH) |
670×401×258mm |
|
EAN |
TBD |
|
Accessories |
|
|
Stand Material / Color |
NA(no stand) |
|
Stand (LxW) |
NA(no stand) |
|
VESA Wall Mount Compatible |
NA(not compatable) |
|
Remote control (Number of Keys / Model number) |
48/ERF3A86(EU)、48/ ERF3B86H(UK)、48/ ERF3C86H(FR)、48/ ERF3D86H(DE)、48/ERF3E86H(ITA)、48/ERF3F86H(ES)、48/ERF3G86H(RU)、48/ERF3K86H(AU)、48/ERF3I86H(ISR)、48/ERF3J86H(SA)、34/ERF3C96H(MEA)、27/ERF3H90H(AP) |
|
Second Remote Control (Model number) |
NA |
|
Remote Batteries |
AAAx2 |
|
User Manual |
YES |
|
Quick start page |
YES |
|
Power cable |
YES |
|
Adapter |
No |
|
Units of packaging material |
carton纸箱1pc+pad 衬垫2pc+TV’s package bag整机袋1pc+accessary bag附件袋2pc+glove package bag 手套包装袋1pc+Cleaning Kit carton清洁套装包装盒1pc+remote control package bag遥控器包装袋1pc+Wrench package bag扳手包装袋1pc |
|
Units of packaging material (0.1g < unit <= 0.5g) |
NA |
|
Units of packaging material (unit > 0.5g) |
carton纸箱1pc+pad 衬垫2pc+TV’s package bag整机袋1pc+accessary bag附件袋2pc+glove package bag 手套包装袋1pc+Cleaning Kit carton清洁套装包装盒1pc+remote control package bag遥控器包装袋1pc+Wrench package bag扳手包装袋1pc |
|
Packaging |
|
|
ISTA 6-AMAZON.com-SIOC |
Yes |
|
Weight of packaging |
2.78kg |
|
Weight of packaging -paper, cardboard |
1.4kg(cardboard 1kg,paper 0.4kg) |
|
Weight of packaging- EPS |
1.7kg |
|
Weight of packaging- foil PE |
0 |
|
Weight of packaging- PVC |
0 |
|
Weight of packaging- plastic- other |
0.03kg |
|
Weight of packaging- wood |
0 |
|
Weight of packaging- metal |
0,05 |
|
Weight of packaging -paper |
0,4 |
|
Logistics & Warranty |
|
|
Container Loading(40HQC) |
392 |
|
DMP formats |
|
|
Container Format |
AVI,MP4,MKV,TS,FLV OGM |
|
Video |
.AVI,.WMV,.MP4,.MOV,.3GP,.MKV,.MPG,.MPEG,.VOB,.FLV,.WebM,.OGM, |
|
Audio |
.wma,.wmv,.mp4,.FLAC,.MP2,.MP3 music(mp3 aac wma wav) |
|
Picture |
.jpeg,.bmp,.PNG,.GIF,.webp |
|
OTHER FEATURES (特殊功能要求） |
|
|
3rd partyRegisterModelName |
120L5H |
|
SAFETY AND REGULATION（安全和认证要求） |
|
|
CE |
Yes |
|
CB |
Yes |
|
EMC 测试 |
Yes |
|
HDMI 认证 |
No |
|
能源之星 |
No |
|
RoHS |
Yes |
|
Divx |
No |
|
CI+ |
Yes |
|
Dolby audio |
Yes |
|
Amazon |
Yes |
|
Netflix |
Yes |
|
YouTube |
Yes |
|
FVP |
Yes |
|
AirPlay |
Yes |
