The Marantz Signature Sound
The Marantz signature sound is defined by warmth, nuance and authenticity. Decades of refinement ensure a natural and balanced presentation that allows listeners to experience their music with greater depth, emotion and realism.
Enhanced Digital Performance
A new high-performance DAC is designed to extract more detail, clarity and depth from every recording. Whether rediscovering a familiar album or exploring something new, it reveals greater nuance and precision—bringing listeners closer to the original performance.
High-Res USB Playback
High-resolution playback via the front USB input supports a wide range of digital formats, including FLAC, ALAC and DSD. This extends performance beyond physical discs, offering flexibility while maintaining exceptional sound quality.
Headphone Amplifier
A fully discrete headphone amplifier, built with HDAM circuitry, delivers dedicated performance for personal listening. With selectable gain and refined tuning, it provides clarity, control, and musicality whether listening through headphones or speakers.
Timeless Marantz Design
Marantz design heritage is expressed through a refined, modern aesthetic. Premium materials, balanced proportions, and subtle detailing create a product that feels both timeless and contemporary—designed to complement any listening space.
Specifications
Features
-
CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AACYes / Yes / No / Yes / Yes / No
-
CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta dataNo / No / Yes / Yes / Yes
-
Data Disc Compatibility: DSD / WAV / ALACNo / No / No
-
DAC Master Clock DesignYes
-
HDAM versionHDAM / HDAM SA2
-
Power Transformer: Toroidal / ElYes / No
-
High Grade Audio ComponentsYes
-
Customised ComponentsYes
-
Symmetric circuit layoutYes
-
Extra metal plate for chassis strengtheningYes
-
Digital out off / Audio EX ModeYes / No
-
Headphone: Standard / Buffer / Current feedbackNo / Yes (HDAM-SA2) / No
Others
-
Selectable filter: CD / SA-CD / DAC-ModeYes / No / No
-
Separated rectifier circuit for analogue and digital circuitryYes
-
Display: Dimmer / OffYes / Yes
-
VFD displayYes
Playback
-
Program Play (CD / SA-CD)25
-
RepeatYes
-
Random PlayYes
Inputs Outputs
-
Analogue Out (Cinch)2ch
-
Digital Optical In / Out0 / 1
-
Digital Coaxial In / Out0 / 1
-
Gold Plated CinchYes
-
USB Audio (Front) / Made for iPod / Made for iPhone®Yes / No / No
-
USB-A: FLAC / WAV / AIFF / ALAC / DSDYes
-
D-BusYes
-
Headphone OutYes
-
Headphone Volume ControlYes
Specifications
-
MechanismYes
-
D/A ConversionYes
-
DAC IC, Digital Filter, Noise ShaperYes
-
Low Pass Filter stage
-
Output Buffer
-
Headphone amp
-
Frequency Response2 Hz - 20 kHz
-
Dynamic Range100 dB
-
Signal to Noise Ratio110 dB
-
Total Harmonic Distortion0.0016%
-
Channel separation98 dB
General
-
Available ColorsBlack / Silver-Gold
-
Metal Front PanelYes
-
Remote ControlRC006PMCD
-
Power Consumption in W32
-
Standby Consumption in W0.3
-
Auto Power offYes
-
Detachable Power CableYes
-
Maximum Dimensions (W x D x H) in inches17.40 × 13.82 × 4.29
-
Weight in lbs.14.3
-
Carton Maximum Dimensions (W x D x H) in inches20.55 × 18.46 × 7.48
-
Carton Weight (inc. product) in lbs19.4
