The Bronze AMS 7G Dolby Atmos speaker featuring the latest 1-inch C-CAM tweeter and 4-inch mid-bass driver is the perfect height-channel speaker for any Bronze Series home cinema system. It allows sound to be ‘fired’ above the listener, depicting objects moving overhead for a fully realistic three-dimensional experience.
It’s thoughtful dimensions and footprint, allow it to suite and sit exactly on top of the Bronze 50 and 300 models, for perfect visual aesthetics.
A starting point for acoustic excellence.
The Bronze AMS 7G is a compact, Dolby Atmos® enabled speaker that adds a whole new dimension to your home cinema system. Designed to sit neatly atop the Bronze 50 or Bronze 300 speakers, it offers both a seamless visual match and easy integration into your setup.
Featuring the latest 1-inch C-CAM gold dome tweeter with UD waveguide and a 4-inch C-CAM bass-mid driver, it delivers precise, immersive height-channel effects for a truly cinematic 3D soundstage. With its sealed cabinet, new crossover design and thoughtful footprint, the Bronze AMS 7G enhances every scene with remarkable realism and spatial clarity.
Bronze AMS 7G - hear it as if you’re really there.
A captivating class leader.
Bronze Series 7G exudes all the qualities you’d expect in terms of craftsmanship and sonic excellence that many have followed, yet very few have bettered.
Bronze has always led and is the entryway into achieving an enhanced listening experience.
A Jewel in the Crown.
One of the more distinct design features on the Bronze Series 7G is the tweeter. The C-CAM gold dome, protected by an aluminium-etched hexagonal grille design, blends seamlessly into the hexagonal waveguide, allowing the high frequencies to reach the listener with the minimum of obstruction to deliver detailed, clear and pristine high fidelity.
Compact, controlled and crystal clear.
The latest incarnation of the Gold Dome tweeter, within Bronze Series 7G, is not only thinner, lighter and more rigid than the previous 6th generation, but its carefully formed profiled dome now benefits from the UD (Uniform Dispersion) Waveguide II. This improves time alignment and allows a lower frequency to crossover for wider directivity.
Delivering life-like clarity.
The Bronze Series 7G utilises a bass-mid driver design that features large magnets and a voice coil, giving this Bronze range much higher power handling and high sensitivity and thus delivering far greater control and more accurate time responses.
What this means is that movie soundtracks, from the quietest to the most dynamic passages or delicate strings to powerful bombastic music passages, are delivered with total realism and neutrality.
Crossover Design – the purest of signals.
The crossovers for Bronze Series 7G have been optimised over many hundreds of hours of listening, each component having been carefully selected by the R&D team. Each component has gone through rigorous measurement testing to improve the overall ‘system design’, and with high-quality capacitors and transistors used – at this price point – the Bronze Series 7G provides detailed and precise sound delivery across all audible sound frequencies for an engaging listen.
Powerful Bronze bass, to move you.
Below the smooth metallic finish of the Bronze Series 7G C-CAM drivers lies a powerful motor system – designed for agility, accuracy and impact.
We’ve introduced a new progressive spider design to ensure smoother, more controlled driver movement, improving excursion linearity. The voice coils on this generation of Bronze are much larger than the previous, now 28.5mm compared to 25mm. The result? Far more bass extension and greater power handling for controlled, punchy, articulate bass.
Specifications
System Format
2-Way
Performance
-
Frequency Response (-6dB, In-Room): 83 Hz — 30 kHz
-
Sensitivity (2.83 Vrms @ 1m, Free-Field): 86 dB
-
Nominal Impedance: 8 Ohms
-
Minimum Impedance (20 Hz - 20 kHz): 3.7 Ohms @ 10 kHz
-
Maximum Peak SPL (AES75, Z-weighted): 110 dB
-
Continuous Power Handling (CTA 426-B): 60 W
-
Recommended Amplifier Power:
-
30 – 120 W into 4 Ohms
-
10 – 60 W into 8 Ohms
-
Acoustic Design
-
Bass Alignment: Sealed
-
Crossover Frequency (LF/HF): 4.8 kHz
-
Drive Units:
-
1 x 4" C-CAM Mid-Range Driver
-
1 x 25mm C-CAM Gold Dome Tweeter with Optimised Waveguide
-
Dimensions & Weight
-
External Dimensions (H x W x D): 173 x 185 x 302 mm (6 13/16 x 7 5/16 x 11 7/8")
-
Packed Dimensions (H x W x D): 271 x 382 x 370 mm (10 11/16 x 15 1/16 x 14 9/16")
-
Weight (each): 3.1 kg (6 lb 13 oz)
Additional Information
-
Sold As: Pair
-
Warranty: 5 Years
