The Dirac Live® Room Correction offers improved musical staging, clarity, dialog, and deeper bass, while the additional two channels create a 5.1.4 Dolby Atmos® immersive surround sound experience.

Klipsch Optimize Mode
Klipsch Optimize Mode allows you to easily integrate your Klipsch Reference and Reference Premiere speakers seamlessly with your Onkyo AV receiver. Klipsch and Onkyo teamed up to implement the precise crossover values for specific new Reference Premiere speakers. Now, you can simply select the model speakers you’ll be using for each individual channel, and the optimized crossover setting will be automatically applied.

Discrete Zone 3 HDMI Switching
Set up different high-definition entertainment options with up to 8K60 resolution* in two different rooms from your Onkyo receiver when the kids don’t feel like partaking in whatever you like or vice versa.**

*8K60 only valid for Zone 1/Zone 2 will only produce 4K120 resolution when two separate HDMI sources are used
**Zone 3 for analog and Net sources only

Take the room out of the equation
State-of-the-art Dirac Live Room Correction technology unlocks your loudspeakers' full potential, improving audio performance across the full frequency band without additional upgrades. Dirac Live automatically calibrates sound in your room using either your smartphone and the included wired mic or virtually wireless with the Dirac Live PC or MacOS* application and a 3rd party USB mic (not included). Now, you'll get a more accurate measurement of your surround sound system's positioning to be more precise and balanced, providing a better result with the increased upper limit of delay time from 20 to 50 milliseconds.

*Device must be connected to the internet and the same network as your AVR

THX Certified
In 1993, Onkyo became the first consumer electronics brand to be THX-certified. With literally thousands of tests, before earning the THX-certification logo: no matter what input is used, no matter what combination of the many built-in features for the AVR, preamplifier, or amplifier, there can be absolutely nothing added, nothing taken away from the source material. The TX-NR7100 offers four distinct THX listening modes: cinema, gaming, music, and surround EX.

Built-In Streaming Services
Access to Spotify®, TIDAL, Deezer, TuneIn, and Pandora® are built into the system. Use dedicated apps (where available) or the free Onkyo Control App for Apple and Android devices to find and play music.

• 220 W/Ch THX® Certified Select DAA system
• IMAX® Enhanced certified for immersive signature
sound by DTS:X®
• 5.2.4-ch/7.2.2-ch Dolby Atmos® and DTS:X playback
• Supports Dirac Live® Room Correction
• AccuReflex phase-matching solution for Atmos-enabled
speakers
• SMART AV Receiver™ Works with Sonos*1,
Chromecast built-in™, AirPlay 2, and DTS Play-Fi®; includes
Spotify®, Amazon Music HD*2, Pandora®, TIDAL, Deezer,
and TuneIn streaming services*3
• Works with Hey Google or Alexa*4
• Stream over 5 GHz/2.4 GHz dual-band Wi-Fi® supporting
the 802.11ac standard*5
• HDMI® inputs 1-3 and Main/Sub outpus support
8K/60p(4:2:0/10-bit), 8K/30p(4:4:4/10-bit),
4K/120p(4:4:4/10-bit) video pass through
• HDMI terminals*9 support HDR10+, Dolby Vision and
BT.2020 color; VRR (Variable Refresh Rate), ALLM (Auto
Low Latency Mode), and QFT (Quick Frame Transport)
passthrough; eARC (Main Out), and HDCP 2.3
• HDMI Sub/Zone 2 Out for media transmission to a
second display
• Send or receive audio via Bluetooth® wireless technology
(RX mode: SBC/AAC, TX mode: SBC/Qualcomm® aptX™/
aptX HD)
• Refined chassis, HDMI board, DAC, Digital/Analog inputs,
power-amp grounds and power lines
• 5.2-ch Main + Powered Zone 2 + Powered Zone 3
speakers support synced/independent D/A audio playback
(including HDMI/SPDIF/NET*6)
• Zone 2/Zone B line-out*7 (analog RCA) supports synced or
independent D/A playback*8 on compatible audio systems
or headphone docks

SPECIFICATIONS
Amplifier Section
Power output (All channels)
220 W/Ch
(6 ohms, 1 kHz, 10% THD,1-ch driven)
100 W/Ch (8 ohms, 20 Hz–20 kHz,
0.08% THD, 2-ch driven, FTC)
Dynamic power 250 W (3 ohms, Front)
220 W (4 ohms, Front)
130 W (8 ohms, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, half power)
Input sensitivity and impedance
200 mV rms/47 k-ohms (Line)
3.5 mV rms/47 k-ohms (Phono MM)
Rated RCA output level and impedance
1 V rms/470 ohms (Subwoofer pre-out)
200 mV rms/470 ohms
(Zone 2/Zone B line-out)
Frequency response 10 Hz–100 kHz/+1 dB,
-3 dB (Direct/Pure Audio)
Tone control ±10 dB, 20 Hz (Bass)
±10 dB, 20 kHz (Treble)
Signal-to-noise ratio 106 dB (Line, IHF-A)
80 dB (Phono, IHF-A)
Speaker impedance 4–16 ohms
Video Section
Input sensitivity/output level and impedance
Video 1.0 Vp–p/75 ohms (Component Y)
0.7 Vp–p/75 ohms (Component Pb/Pr)
1.0 Vp–p/75 ohms (Composite)
Tuner Section
Tuning frequency range
FM 87.5 MHz–107.9 MHz
AM 530 kHz–1,710 kHz
FM/AM preset memory 40 stations
General
Power supply AC 120 V~, 60 Hz
Power consumption (operating)
750 W
Power consumption (idle) 75 W
Power consumption (standby)
0.1 W
Dimensions (W x H x D) 17 1/8˝ x 6 13/16˝ x 14 15/16˝
(435 x 173.5 x 379.5 mm)
Weight 22.9 lbs. (10.4 kg)
UPC CODE
(B) 889951003496
CARTON
Dimensions (W x H x D) 21˝ x 10 7/16˝ x 18 7/16˝
(534 x 265 x 468 mm)
Weight 29.8 lbs. (13.5 kg)
