FEATURES
• TA-210 is a static balanced gimbal type arm, easy to use and adjust for optimal VTF settings
• TA-210 has a standard 5-pin DIN connector for tonearm cable
• The tonearm geometry allows for a Baerwald alignment (also the IEC recommendations)
• Counterweight with Inner/outer scale
- Inner scale to be applied with the main counterweight
- Outer scale to be applied when the extra mass ring is added
• Counterweight will work with headshell+cartridge mass approximately in the range 20 to 28g
• TA-210 is fitted with a standard headshell connector and can easily be adjusted in accordance with the included mounting template
• Extra mass ring for heavier cartridge and headshell combinations included (the extra mass ring may need to be attached to achieve proper tracking force)
• Extra mass ring weight 45g
TA-210 Technical data
TECHNICAL DATA
Effective mass without headshell: 5 g
Effective armlength (distance between the stylus and pivot point): 329.0 mm
Mounting distance (distance between the pivot point and turntable center): 316.6 mm
Offset angle: 16.5 degrees
Overhang: 12.4 mm
Tracking force adjusting range direct reading: 0-3 g
Tracking force adjusting range with extra mass ring mounted: 0-4 g
Height adjustment range: 35-55 mm
The diameter of the arm base mounting hole: 19-20 mm
The diameter of the center shaft of tonearm: 18.0 mm
Inner null point: 66 mm
Outer null point: 120.9 mm
Counterweight for cartridge + headshell mass between 21 and 28g included
Headshell LH-2000E included weight: 15.5 g
TA-210 total weight including headshell: 536 g
Set of tonearm cables 6NX-TSW-1010 included
Extra mass ring for heavier cartridges included weight: 45 g
Extra mass ring for heavier cartridge-and-headshell combinations
The extra mass ring may need to be attached to achieve the proper tracking force.
The counterweight should be attached to the rear of the tonearm with the inner number scale facing forward. If the extra mass ring is needed, it must be installed prior to attaching the counterweight to the tonearm.
The extra mass ring should be installed on the back of the counterweight and may need to be twisted slightly to facilitate the installation.
Ensure that the extra mass ring fits tightly to the thick part of the counterweight
TA-210 is the product with great benefits for the discerning analog user
The TA-210 can ideally be combined with the MC Windfeld Ti, MC A95, SPU Series, and the Ortofon Xpression. For SPU Series the extra mass ring may need to be attached to achieve proper tracking force.
The combination of Xpression, the ST-80 SE Moving Coil transformer, and the TA-210 gives a supreme experience!
The High-end headshell LH-10000, incorporating damping technology similar to the TA-110/210 tonearms, will be a perfect interface between the tonearms and the Ortofon Cadenza Series, MC Windfeld Ti and MC A95.
The effect of the rubber and TPE damping properties
The TA-210 is given a precision machined slit at each end of the aluminum tube. A piece of Ortofon special vibration damping compound is integrated into each slit:
• Rubber inserts with high vibration damping properties integrated into the bottom slot of the arm tube
• Special proprietary TPE compound with excellent damping properties integrated into the top slot of the arm tube
Due to these two different materials, an extended damping effect is obtained in the largest possible range. Both inserts integrated in the tonearm tube are manufactured at the Ortofon technical facilities in Nakskov, Denmark.
TA-210 arm tube is less stressed than TA-110 and a lot less stressed than conventional arm tubes due to the Technical rubber and TPE excellent damping properties.
