The Quintet Bronze moves into the higher league of the Quintets.
The slim profile of its Nude Fine Line diamond stylus will track even the highest frequency information, making it a must for discerning listeners.
Additionally, its larger footprint ensures reduced distortion and record wear.
The sound will be very even-handed with respect to all aspects. Classical music will be reproduced with power and open space around each of the instruments.
Output voltage at 1000 Hz, 5cm/sec. - 0.3 mV
Channel balance at 1 kHz - < 1.2 dB Channel separation at 1 kHz - > 23 dB
Channel separation at 15 kHz - > 15 dB
Frequency range at - 3dB - 20-25.000 Hz
Frequency response 20-20.000 Hz - +/-1.5 dB
Tracking ability at 315Hz at recommended tracking force * - 80 æm
Compliance, dynamic, lateral - 15 æm/mN
Stylus type - Nude Fine Line
Stylus tip radius - r/R 8/40 æm
Tracking force range - 2.1-2.5 g 21-25 mN
Tracking force, recommended - 2.3 g 23 mN
* Typical value
Tracking angle - 20ø
Internal impedance, DC resistance - 5 Ohm
Recommended load impedance - > 20 Ohm
Cartridge body material - ABS/Aluminium
Coil wire material - Pure 4-nines copper
Cartridge colour - Bronze
Cartridge weight - 9 gram
ORTOFON MC QUINTET BRONZE MCC
