Performance & Value
To produce a loudspeaker that meets our standards for performance and value, we took complete control of the manufacturing process, an unprecedented move at this price point. In our state-of-the-art North American facility, we have produced a loudspeaker that defies convention; a homegrown loudspeaker that benefits from innovations found throughout the Paradigm family of loudspeakers.
Patented Perforated Phase-Aligning (PPA™) Tweeter and Midrange Lens Technology
Patented Active Ridge Technology (ART™) Surrounds
- Crossover: 2nd-order electro-acoustic at 2.5 kHz (tweeter/mid) and 600Hz (mid/woofers)
- High Frequency Driver: 1” (25mm) X-PAL™ dome, ferro-fluid damped/cooled, Perforated Phase-Aligning Tweeter (PPA™) Lens
- Frequency Response On-Axis: ±3dB from 73 Hz - 25 kHz
- Frequency Response 30° Off-Axis: ±3dB from 73 Hz - 20 kHz
- Midrange Frequency Driver: 4” (102mm) Black Anodized X-PAL™ cone, Perforated Phase-Aligning (PPA™) Lens
- Low Frequency Driver: Two 5-1/2” (140mm) ART™ Surround Carbon-Infused polypropylene cones
- Sensitivity (Room/Anechoic): 92 dB / 89 dB
- Low Frequency Extension: 47 Hz (DIN)
- Suitable Amplifier Power Range: 15 - 120 watts
- Maximum Input Power: 80 watts
- Impedance: Compatible with 8 ohms
- Finishes: Gloss Black, Gloss White, Espresso Grain MK 2
- Dimensions (H x W x D): 7.125" × 20.125" × 13.75" (18cm × 51.5cm × 32cm)
- Weight: 26 lbs. (11.8 kg)
