Plinius 9100 Integrated Amplifier (Each)

Gallery
Description

Description

PRODUCT SPECIFICATIONS

Power: 120 Watts RMS per channel into 8 Ohms. Both channels driven from 20Hz to 20kHz at less than 0.1% total harmonic distortion
Frequency Response: 20Hz to 20kHz ± 0.2dB. 0dB at 0Hz and -3dB at 70kHz
Distortion: Typically <0.05% THD at rated power. 0.1% THD & IM worst case prior to clipping
Current Output: 20A short duration peak per channel. Fuse protected
Slewing: 50V/us
Hum & Noise: 90dB below rated output 20Hz to 20kHz unweighted
Input Sensitivity: 290mV RMS for rated output at 1kHz
Input Impedance: 47k Ohms
Input Overload: 5V RMS
Rated Pre Out Level: 1.5V RMS into 47k Ohms or higher
Pre Out Source Impedance: Typically 1.5k Ohms
Pre Out Minimum Recommended Load: 47k Ohms
Tape Output Level: Unity Gain at 200mV. Tape loop muting at 5V RMS input
Dimensions: Height 105mm (4"), Width 450mm (17.75"), Depth 400mm (15.75"), Weight 10kg (22lb)

PLINIUS 9100 - PO

Plinius 9100 Integrated Amplifier (Each) | Pre-Owned

R 22,990.00

R 53,000.00R 30,010.00 OFF

Select quantity

Lucky you 🤩 Only 1 left in stock! Buy now.

E-CREDIT, NOW AVAILABLE
E-Credit finance on orders with a minimum value of R50 000. Learn More.

Description

PRODUCT SPECIFICATIONS

Power: 120 Watts RMS per channel into 8 Ohms. Both channels driven from 20Hz to 20kHz at less than 0.1% total harmonic distortion
Frequency Response: 20Hz to 20kHz ± 0.2dB. 0dB at 0Hz and -3dB at 70kHz
Distortion: Typically <0.05% THD at rated power. 0.1% THD & IM worst case prior to clipping
Current Output: 20A short duration peak per channel. Fuse protected
Slewing: 50V/us
Hum & Noise: 90dB below rated output 20Hz to 20kHz unweighted
Input Sensitivity: 290mV RMS for rated output at 1kHz
Input Impedance: 47k Ohms
Input Overload: 5V RMS
Rated Pre Out Level: 1.5V RMS into 47k Ohms or higher
Pre Out Source Impedance: Typically 1.5k Ohms
Pre Out Minimum Recommended Load: 47k Ohms
Tape Output Level: Unity Gain at 200mV. Tape loop muting at 5V RMS input
Dimensions: Height 105mm (4"), Width 450mm (17.75"), Depth 400mm (15.75"), Weight 10kg (22lb)
