How to Improve on a Legend
While the original intent has not changed, today’s Alpha designs benefit greatly from improved materials and production techniques, not to mention an additional 30 years of experience. These new Alpha models are ‘clean sheet” designs taking full advantage of the latest available technologies to create speakers that are smooth and dynamic with the ability to express the full range of musical sounds with nothing added and nothing taken away.
Improved Drivers and Materials
For the new Alpha P5, PSB developed a new 5 ¼” woofer employing dual layer voice coils with powerful magnets and polypropylene cones for detail, low distortion and power handling. A new ¾” (19mm) tweeter is ferrofluid cooled and features a Neodymium magnet for high sensitivity and power handling. A wave guide on the front of the tweeter helps match the response of the tweeter near the crossover point with the woofer for a seamless transition. Of note, the tweeter is placed below the woofer on some models which, in concert with the precisely engineered crossover network, provides a uniform sound field whether the listener is seated or standing.
Unsurpassed Value
In keeping with the Alpha philosophy, the P5 indeed represents remarkable value for its size and performance. In fact, though the new models easily outperform the originals, all of the new Alphas are slightly cheaper than the original models, when adjusted for inflation. Better performance for less money means outstanding value.
SPECIFICATIONS
On Axis @ 0° ±3dB
55-21,000Hz
On Axis @ 0° ±1 1/2dB
65-20,000Hz
Off Axis @ 30° ±1 1/2dB
65-10,000Hz
LF Cutoff -10dB
37Hz
Anechoic Chamber
87dB
Listening Room
89dB
Nominal
8 Ohms
Minimum
4 Ohms
Recommended
10 – 90 Watts
Program
60 Watts
Tweeter (Nominal)
3/4” (19mm) Black Anodized Aluminium Dome with Ferrofluid and Neodymium Magnet
Woofer (Nominal)
5 1/4” (133mm) Textured Polypropylene Cone with Rubber Surround
Crossover
2.500Hz, L4
Internal Volume
0.29 cu ft (8.3L)
Design Type
Tuned Port Bass Reflex, 2” (49mm) Rear Port
Size (W x H x D)
6 3/4” x 11 3/8” x 9 1/2”*
(170 x 290 x 240mm)
Weight
10.15lb (4.6kg)/each
22.8lb (10.4kg)/pr
Finish**
Black Ash
Walnut
