M&K C15S Custom Installation Sub (Each)

Gallery
Description

Description

Bigger is better when it comes to bass.

Falling between the X10 and X12 in total woofer area, the C15S is a no-compromise bass machine.
Designed for behind the screen installations the C15S is only 298mm deep, same as the S150.
Full 1″ MDF cabinet construction with full center brace with additional front to back braces for Ultra-rigid cabinet construction.
Included Bass Brace brackets for bolting down to the floor/stage for safety, security and increased vibration reduction.
Included Stacking Coupler for stacking multiple subwoofer for additional output.
Separate subwoofers and amplifiers increase thermal performance.
External amp – VA500 Blue tuned specifically for the C15S with 3 custom boundary compensation EQ´s.
The C15S builds on the technology of the X-Series and V-Series subwoofers and goes BIG. With output on par with the dual 10” X-10 subwoofer (without the advantages of Push-Pull) in a single driver enclosure, the C15S is designed to enhance custom and large installations.

Utilizing a specially tuned VA-500 amplifier, the entire system was custom designed from the ground up to reproduce the deepest notes at levels loud to be heard and felt.

Specifications

Sound Specifications:

Nominal System Impedance: 4 ohm (Z-min 3.4 ohm)
Frequency Response: 22-200Hz +/-3dB (average response in room +/- 3 dB)
Frequency Roll Off: 20 Hz (-6 dB at 20 Hz near field)
Crossover Frequency: Variable, 60-200Hz (VA500 Blue)
Tweeter: Not Applicable (NA)
Woofer: 1 x 15″ Ultra-Stiff Paper Pulp with fiberglass dustcap
Power Handling:
- 800 watts Long term IEC-268-5 (cycled input 77-20K Hz)
- 500 watts Rated IEC-268-5 (constant input 77-20K Hz)
Recommended Amp Power: VA500 Blue
Sensitivity: 91dB Drive Signal 100mV VA500 Blue Input
Max SPL (Sound Pressure Level):
- Continued: 118 dB Sinewave 40-200Hz / THD 10%
- Peak: 121 dB Sinewave 40-200Hz / THD 10%
System Principle: Sealed Full 1’’ MDF enclosure

Colors:

Finish: Paint - Black Vinyl

Dimensions:

Cabinet Dimensions (H x W): 28.54 x 19.60 inches / 725 x 498 mm
Cabinet Depth (D): 11.73 inches / 298 mm
Dimensions Grille: Not Available (NA)

Accessories:

2 x ‘’Brass Brace’’ Rigid Bracket
2 x Stacking Couple Straight Brackets
4 x Rubber Feet
4 x Foam Protectors

Weight:

Net Weight: 71.6 lbs / 32.5 kg

M&K C15S

M&K C15S Custom Installation Sub (Each)

R 64,999.00

In our constant strive to be the BEST “go-to-speakers” for Home Cinema installations we have developed the real NO Compromise Bass machine.Introducing the C15S Custom Install Subwoofer. Designed for custom installations

Select quantity

E-CREDIT, NOW AVAILABLE
E-Credit finance on orders with a minimum value of R50 000. Learn More.

Description

Bigger is better when it comes to bass.

Falling between the X10 and X12 in total woofer area, the C15S is a no-compromise bass machine.
Designed for behind the screen installations the C15S is only 298mm deep, same as the S150.
Full 1″ MDF cabinet construction with full center brace with additional front to back braces for Ultra-rigid cabinet construction.
Included Bass Brace brackets for bolting down to the floor/stage for safety, security and increased vibration reduction.
Included Stacking Coupler for stacking multiple subwoofer for additional output.
Separate subwoofers and amplifiers increase thermal performance.
External amp – VA500 Blue tuned specifically for the C15S with 3 custom boundary compensation EQ´s.
The C15S builds on the technology of the X-Series and V-Series subwoofers and goes BIG. With output on par with the dual 10” X-10 subwoofer (without the advantages of Push-Pull) in a single driver enclosure, the C15S is designed to enhance custom and large installations.

Utilizing a specially tuned VA-500 amplifier, the entire system was custom designed from the ground up to reproduce the deepest notes at levels loud to be heard and felt.

Specifications

Sound Specifications:

Nominal System Impedance: 4 ohm (Z-min 3.4 ohm)
Frequency Response: 22-200Hz +/-3dB (average response in room +/- 3 dB)
Frequency Roll Off: 20 Hz (-6 dB at 20 Hz near field)
Crossover Frequency: Variable, 60-200Hz (VA500 Blue)
Tweeter: Not Applicable (NA)
Woofer: 1 x 15″ Ultra-Stiff Paper Pulp with fiberglass dustcap
Power Handling:
- 800 watts Long term IEC-268-5 (cycled input 77-20K Hz)
- 500 watts Rated IEC-268-5 (constant input 77-20K Hz)
Recommended Amp Power: VA500 Blue
Sensitivity: 91dB Drive Signal 100mV VA500 Blue Input
Max SPL (Sound Pressure Level):
- Continued: 118 dB Sinewave 40-200Hz / THD 10%
- Peak: 121 dB Sinewave 40-200Hz / THD 10%
System Principle: Sealed Full 1’’ MDF enclosure

Colors:

Finish: Paint - Black Vinyl

Dimensions:

Cabinet Dimensions (H x W): 28.54 x 19.60 inches / 725 x 498 mm
Cabinet Depth (D): 11.73 inches / 298 mm
Dimensions Grille: Not Available (NA)

Accessories:

2 x ‘’Brass Brace’’ Rigid Bracket
2 x Stacking Couple Straight Brackets
4 x Rubber Feet
4 x Foam Protectors

Weight:

Net Weight: 71.6 lbs / 32.5 kg
