Key Features
- 6,000-lumen brightness Crisp images and bright colours, even in well-lit rooms
- WUXGA resolution Sharp Full HD images for excellent clarity
- Futureproofed connectivity options 4K input support, HDMI, HDBaseT, integrated Wi-Fi, and screen mirroring
- Easy, flexible installation Lightweight and compact design with wide lens shift
- Short-throw projection Large images in tight spaces (0.8:1 throw ratio)
Specifications
Image and Display:
- Projection System: 3LCD Technology, RGB liquid crystal shutter
- LCD Panel: 0.67 inch with C2 Fine
- Color Light Output: 6,000 Lumen (IDMS15.4) - 4,200 Lumen (economy)
- White Light Output: 6,000 Lumen - 4,200 Lumen (economy) (ISO 21118:2020)
- Resolution: WUXGA
- Resolution Enhancement: Full HD
- Aspect Ratio: 16:10
- On-Screen Pixel Count: 2,304,000
- Contrast Ratio: Over 5,000,000:1
- Colour Reproduction: Up to 1.07 billion colours
- Colour Video Processing: 10 Bits
Lens and Optical:
- Light Source: Laser
-
Laser Light Source Life:
- 20,000 hours (High Durability)
- 30,000 hours (Eco Durability)
- Throw Ratio: 0.80:1
- Zoom: Digital, Factor: 1 - 1.35
- Lens: Optical
- Lens Shift: Manual - Vertical ± 50%, Horizontal ± 20%
- Screen Size: 50 inches - 200 inches
- Projection Distance Wide: 0.9 m - 3.5 m
- Projection Lens F Number: 1.7
- Projection Lens Focal Length: 11.76 mm
- Projection Lens Focus: Manual
Connectivity and Features:
-
Interfaces:
- USB 2.0-A
- USB 2.0
- RS-232C
- Ethernet Interface (100 Base-TX / 10 Base-T)
- Wireless LAN IEEE 802.11a/b/g/n/ac
- Wireless LAN a/n (5GHz)
- VGA in (2x)
- VGA out
- HDMI out
- HDBaseT
- Miracast
- Jack plug out
- Jack plug in (2x)
- HDMI (HDCP 2.3) (2x)
- USB 2 Type A playback
- Epson iProjection App: Ad-Hoc / Infrastructure
- Network Protocol: HTTPS, IPv6, SNMP, ESC/VP.net, PJLink
- Security Features: Kensington lock, Control panel lock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
- 2D Colour Modes: Dynamic, Cinema, Presentation, sRGB, DICOM SIM
-
Other Features:
- 21:9 aspect ratio support
- A/V mute
- Arc Correction
- Auto Power On
- Auto source search
- Built-in speaker
- CEC compatible
- Customizable user logo
- Daisy chain Multi-Projection
- Digital zoom
- Direct Power on/off
- Document Camera Compatible
- Edge Blending
- Home Screen
- Horizontal and vertical keystone correction
- JPEG Viewer
- Long light source life
- PC Free
- Power on button
- Quick Corner
- Schedule Function
- Screen Mirroring
- Split-Screen-Function
- Super resolution
- Ultra-wide display (16:6)
- Volume control
- Web Control
- Web Remote
- Wireless LAN capable
- iProjection App
- Video Color Modes: Cinema, Dynamic, Presentation, sRGB, DICOM SIM, Multi Projection
- Projector Control: Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Build and General Specifications:
-
Power Consumption:
- Normal On-Mode: 287 Watt
- Eco On-Mode: 164 Watt
- Normal Peak-Mode: 345 Watt
- Eco Peak-Mode: 258 Watt
- Energy Saving Standby: 0.3 Watt
- Supply Voltage: AC 100 V - 240 V, 50 Hz - 60 Hz
- Product Dimensions: 440 mm x 334 mm x 136 mm (WxDxH)
- Product Weight: 8.4 kg
-
Noise Level:
- Normal: 38 dB (A)
- Economy: 27 dB (A)
-
Supported Temperature:
- Storage: -10° C - 60° C
-
Supported Humidity:
- Operation: 20% - 80%
- Storage: 10% - 90%
- Options: Connection and control box, Document camera, External Speaker, HDBaseT Transmitter, MB22 ceiling mount, Wireless LAN unit
- Loudspeaker: 10 Watt
- Room Type / Application: Boardroom, Large Meeting Room / Auditorium, Meeting room / Classroom, Projection Mapping, Signage / Retail, Visitor Attraction
- Positioning: Ceiling Mounted, Desktop
- Colour: White
- Warranty: 36 months Carry in
