Incredible Color
WUXGA with 4K Enhancement1
Long-lasting laser light source
Simplified installation
Engineered for reliability
Outstanding image quality
Image and Display:
- Projection System: 3LCD Technology
- LCD Panel: 1.03 inch with C2 Fine
- Color Light Output: 13,000 Lumen (IDMS15.4) - 9,100 Lumen (economy)
- White Light Output: 13,000 Lumen - 9,100 Lumen (economy) (ISO 21118:2020)
- Resolution: WUXGA
- Resolution Enhancement: 4K enhancement
- Aspect Ratio: 16:10
- Contrast Ratio: Over 5,000,000:1
- Native Contrast: 2,000:1
- Colour Reproduction: Up to 1.07 billion colours
- HDR Support: HDR10, HLG
- Colour Video Processing: 10 Bits
Lens and Optical:
- Light Source: Laser
-
Laser Light Source Life:
- 20,000 hours (High Durability)
- 30,000 hours (Eco Durability)
- Throw Ratio: 0.35 - 7.41:1
- Zoom: Motorized, Factor: 1 - 1.6
- Lens: Varies by lens
- Lens Shift: Motorized - Vertical ± 60%, Horizontal ± 18%, varies by lens
- Lens Position Memory: 10 positions
- Screen Size: 60 inches - 1,000 inches (varies by lens)
- Projection Distance: Varies by lens
- Projection Lens Focus: Motorized
- Interchangeable Lens: Yes
- Standard Lens: Not included
Connectivity and Features:
-
Interfaces:
- USB 2.0-A (2x)
- USB 2.0 Type B (Service Only)
- RS-232C
- Ethernet Interface (1000 Base-T/100-Base TX/10-Base-T)
- VGA in
- DVI in
- HDMI in
- HDBaseT
- Jack plug out
- Wireless LAN IEEE 802.11a/b/g/n (optional)
- Near Field Communication (NFC)
- USB content playback
- Remote
- Network Protocol: HTTPS, IPv6, SNMP, ESC/VP.net, PJLink
- Security Features: Kensington lock, Security bar, Password lock, Wireless LAN unit lock, Wireless LAN security, Password protection
-
Other Features:
- 21:9 aspect ratio support
- 4K enhancement
- A/V mute
- Auto Power On
- Auto source search
- Direct Power on/off
- Edge Blending
- Freeze image
- Horizontal and vertical keystone correction
- Lens position memory
- Long light source life
- OSD copy function
- Point correction
- Power on button
- Quick Corner
- Schedule Function
- Split-Screen-Function
- Super resolution
- Web Control
- Web Remote
- iProjection App
- Video Color Modes: Cinema, Dynamic, Natural, Presentation, DICOM SIM, Multi Projection, BT709
- Projector Control: AMX, Crestron, Extron
Build and General Specifications:
- Sealed Light Source Module: Yes, IP5X rated
- Sealed Optical Engine: Yes, IP5X rated
-
Power Consumption:
- Normal On-Mode: 686 Watt
- Normal Peak-Mode: 864 Watt
- Eco Peak-Mode: 633 Watt
- Energy Saving Standby: 0.4 Watt
- Heat Dissipation: 2,938 BTU/hour (max)
- Supply Voltage: AC 200 V - 240 V, 50 Hz - 60 Hz
- Product Dimensions: 586 mm x 492 mm x 218 mm (WxDxH)
- Product Weight: 23.8 kg
-
Noise Level:
- Normal: 34 dB (A)
- Economy: 29 dB (A)
-
Supported Temperature:
- Storage: -10° C - 60° C
-
Supported Humidity:
- Operation: 20% - 80%
- Storage: 10% - 90%
- Included Software: Epson Creative Projection, Epson Projector Config Tool, Epson Projector Content Manager, Epson Projector Management, Epson Projector Professional Tool
- Options: Camera module, Ceiling mount, Wireless LAN unit
- Room Type / Application: Boardroom, Large Meeting Room / Auditorium, Meeting room / Classroom, Projection Mapping, Rental / Staging, Signage / Retail, Visitor Attraction
- Positioning: Ceiling Mounted, Desktop, Flying Frame
- Colour: White
- Warranty: 36 months Carry in
