Specifications:
Model Information:
- Series: L9
- Internal Model: 100L9HE
- Retail Model: 100L9H/100L9/100L9HE
- PRD Address: Link
- Built-in Video SVN: Link
- EPOS SVN: Link
- Online Model: NA
Basic Information:
- ID Color: Black, Gray
- Resolution: 4K
- Aspect Ratio: 16:9
- Display Technology: DLP
- Light Source: Laser Source
- Light Source: Blue+Green+Red Laser
- DMD: 0.47”
- Throw Ratio: 0.25
- Audible Noise: 32dB
- Display Surface: Flat
- Lens Shift: No
- Focus: No
- Zoom (Optical or Digital): No
- Lens Cover: No
- Light Source Lifetime: 25,000 hours (Luminance drop 50%)
- Eye Protection (Automatic turn off laser when people close by): Yes
- Resistant (IP Level): NA
- Kensington Security Slot: Yes
- RoHS Compliant: Yes
- Recyclable Product: Yes
- Speakers/Type: Built-in
- Audio Power Output: No
- Screen Size (Class): 100“
- Screen: 100″
- Screen Type: Fresnel Lens Technology & Black/White Lenticular Technology
- Category: 4K Smart Laser TV
- UI: VIDAA U6
Technical Details:
- Luminance (Peak, full field, in Lumens): Peak: 3000lm
- Brightness: 400nit
- Static Contrast: >1000:1 (Based on prototype tested data)
- Dynamic Contrast Ratio: 200,0000:1
- Number of Colors: 1.07B
- Resolution: 3840*2160
- 4K Upscaling: Yes
- 10-bit Colorimetry: Yes
- HDR Compatible: Yes
- HDR10: Yes
- HLG: Yes
- HDR10+ Decoding: Yes
- Dolby Vision: Yes
- HDMI-ARC Support: Yes
- HDMI-CEC Support: Yes
- MHL Support: No
- Anyview Cast (Miracast): Yes
- Network Streaming (DLNA): Yes
- Wireless Digital Audio (Bluetooth): Yes
- FILMMAKER MODE: Yes
- Wide Color Gamut: Typical NTSC 145% (137.75%-152.25%)
- 3D: No
- Processor: MT9900
- Upscaling Ultra HD: Yes
- MEMC: Yes
- Frame Rate: 60Hz
- Motion Rate: 120
- Decoder: HEVC (H.265), VP9, H.264, MPEG4, MPEG2, VC1, MVC
- Input Lag in Game Mode: ≤120ms
- 3D Digital Comb Filter: Yes
- MPEG Noise Reduction: Yes
- Mosquito Noise Reduction: Yes
Sound:
- Sound Output Power: 2*20W
- Subwoofer: NA
- Sound Technology: Dolby Atmos
- NICAM/A2 Stereo: NICAM Stereo
- User Equalizer: Yes (Advanced Parametric Equalizer, the compensation of frequency characteristics based on input signal level to fit the acoustic characteristics of human ears)
- Sound – Special: Dolby Audio(MS12) Dolby Atmos
- AC-4: Yes
- MPEG-H: No
Convenience:
- Media Player: Yes (Video, Audio, Picture)
- Multi-Language OSD: English, Français, Deutsch, Italiano, Español, Português, Svenska, Dansk, Suomi, Norsk, Čeština, Slovenčina, Polski, Magyar, Български, Türkçe, 中文, Русский, O’zbekiston, العربية, हिंदी, Arabic, Hindi, Latvija, Eesti, Lietuva
- Hotel TV: Yes
- User Interface: VIDAA U6
Internet:
- Important Apps (All Countries): Netflix, YouTube, Prime Video (Amazon), Airplay
- Country-Specific Apps: Freeview Play (UK), Maxdome (GER), Timvision(IT), ChiliTV(IT), BBC iPlayer(UK), Mitele(SPAIN), RTVe(SPAIN), IVI(RUS), OKKO(RUS), MEGOGO(RUS, UKR), Rutube(RUS), Channel One(RUS); Rai Play(IT); RMC (SFR sports)(FRANCE), OLL TV(UKR), Divan.TV(UKR), CDA.PL(POL)
- Web Browser: Odin
- HbbTV: V2.0.2
- MHEG Support: Yes, (but only if Certification requires, e.g. Ziggo)
- Anyview Cast: Yes
- Anyview Stream: Yes (DMP, DMR)
- Smartphone App: VIDAA APP
Reception and TV Features:
- Digital and Analog Tuner: DVB-T2/T/C/S2/S
- Twintuner: No
- LCN Support: Yes (Depending on location and operator)
- Teletext Support: Yes
- EPG: 7 days forward EPG, 7 days backward EPG (UK Only), 8-Day EPG: Yes
- Parental Control: Yes
- PVR: Yes
- Time Shift: Yes
- Channel Sorting: Built-in and exportable for PC edit (ChSort)
- Favorite Channel List: 4
Connectivity:
- Common Interface (CI+): Yes(V1.4)
- HDMI1: HDMI2.1(ALLM)
- HDMI2: HDMI2.1(ALLM, eARC)
- HDMI3: HDMI2.0
- USB (2.0): 1
- USB (3.0): 1
- S/PDIF Output: 1
- RCA L/R Output (Analog): 0
- Headphone Output: 1
- RF Tuner: 2
- Composite
