• 1 x 7" (178 mm) RST II dual-coil bass driver for pristine mid-range and full bass
• Patented Quik-Link speaker cable connector for quicker installation (UK patent application no. 2216966.8)
• Tri-Grip II for easy and secure fitment

Specifications

System Format: 2–Way

Channels:

• Mono: 1
• Stereo: 2

Frequency Response, Installed (-6dB): 35 Hz – 30 kHz

Nominal Impedance:

• Mono: 4 Ohm
• Stereo: 8 Ohm

Minimum Impedance (20Hz to 20kHz):

• Mono: 3.4 Ohm @ 15 kHz
• Stereo: 6.8 Ohm @ 15 kHz

Sensitivity (2.83Vrms@1m, Installed): 86 dB

Maximum Peak SPL (single speaker @ 1m Z-Weighted):

• Mono: 114 dB

Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor):

• Mono: 150 W
• Stereo: 2 x 75 W

Recommended Amplifier Power (RMS into 8 OHM, Music Signal):

• Mono: 40 – 150 W
• Stereo: 2 x 20 – 75 W

Drive Unit Complement:

• 1 x 7" (178 mm) RST II dual-coil bass driver
• 2 x 1" (25 mm) C-CAM tweeter

Crossover Frequency: LF/HF: 2.25 kHz

Mounting Depth: 99 mm (37/8")

Cut-Out Hole Diameter: 212 mm (83/8")

External Dimensions (Including Grille - H x W x D): 242 x 242 x 103​ mm (91/2 x 91/2 x 44/16")

Weight (each): 2.1 kg (4 lb 10 oz)

Pre-Construction Bracket: CM-B

Cabinet Finish: Matt black & Orange​ & Bronze

Sold As: Single Unit

Switches:

• Corner Switch: On/Off
• HF Switch: - /0/ +
• Music/Movie Switch: Music/Movie
• Mono/Stereo Switch: Mono/Stereo
