Specifications

Design:

• 2-driver, 2-way vented die-cast aluminum enclosures with integrated baffle and chassis.
• Low-diffraction grilles maximize imaging and ensure smooth dispersion.

Crossover:

• 3rd-order electro-acoustic at 2.2 kHz.

Drivers:

• High-Frequency Driver: 25-mm (1 in) S-PAL™ satin-anodized pure-aluminum dome.
• Mid/Bass Frequency Driver: 102-mm (4 in) S-PAL™ satin-anodized pure-aluminum dome.

Frequency Response:

• On-Axis: ±2 dB from 120 Hz - 20 kHz.
• 30° Off-Axis: ±2 dB from 120 Hz - 18 kHz.

Sensitivity (Room / Anechoic):

• 89 dB / 86 dB.

Low Frequency Extension:

• 76 Hz (DIN).

Power Handling:

• Suitable Amplifier Power Range: 15 - 100 watts.
• Maximum Input Power: 50 watts.

Impedance:

• Compatible with 8 ohms.

Finishes:

• Gloss Black, Gloss White.

Dimensions (H x W x D):

• 7.75" × 4.5" × 5.75" (19.7cm × 11.4cm × 14.6cm).

Weight:

• 5.4 lbs. (2.45 kg).

Accessories (Included):

• Bookshelf/Tabletop Stands and Wall Brackets.
