Description

Today’s home audio applications demand solutions that traditional designs are simply not able to fulfill. Regardless of the installation, PSB believes that the sound should never be compromised. PWM Series melds refined, elegant looks, versatile application and unwavering performance.

The slim profile hugs the wall and maintain a minimal visual presence. Their clean and simple lines complement virtually any design aesthetic. Interior designers, architects, custom home builders and system integrators will appreciate the understated elegance and highest performance levels offered by the Performance Wall Mount Series.

Newly developed drivers employing four-layer voice coils with powerful magnets and carbon fiber cones for exceptional detail, low distortion and superior power handling. The new proprietary 1” titanium dome tweeter is ferrofluid cooled and features a Neodymium magnet for high sensitivity and power handling. A wave guide on the front of the tweeter helps match the response of the tweeter near the crossover point with the woofer for a seamless transition.

Whether as part of a complete on-wall system, a basic TV application or as an on-wall center channel solution for floor standing speakers; PWM series deliver legendary PSB sonic performance coupled with aesthetics and install cues desired in today’s interior design.

Key Features:

  • Slim Profile premium On-Wall speaker system
  • 2 x 4” woofers with carbon fiber cones, rubber surrounds
  • 1” Titanium Dome Tweeter
  • Vertical or horizontal mounting options
  • Wall mount bracket included
  • LCR or for surround speaker application
  • Design and final voicing engineered by Paul Barton
  • Available in Satin White or Satin Black

SPECIFICTAIONS

Sensitivity

Anechoic Chamber

85dB

Typical Listening Room

87dB

Frequency response

On Axis +/- 3db

70Hz-23kHz

LF Cutoff

50Hz

Impedance

Normal

8 Ohms

Minimum

6 Ohms

Recommended Amplifier Power

Tweeter (Nominal)

1″ (25mm)
Titanium Dome with Ferrofluid

Woofer (Nominal)

2x 4″ (100mm)
Carbon Fibre Cone Rubber Surround
Cast Basket

Design Type

Bass Reflex

Construction

Cabinet

MDF

Grille Face

Acoustic Transparent Cloth

Frame

MDF

Size (W x H x D)

Net H

28” (711mm)

Net W

6.5” (165mm)

Net D

3.38” (85mm)

Shipping Information

Shipping H

11.38” (288mm)

Shipping W

32” (864mm)

Shipping D

9” (228mm)

Volume

2.02 cu ft (0.06㎥)

Weight (LB)

Net – 14 lbs (6.4 kg)
Shipping – 20.1 lbs (9.1 kg)

Finish

Available Finishes

Satin Black, Satin White

Grille Type

Magnetic, Cloth Grille

Mount

Wall Bracket

Wall Mount included for Vertical and Horizontal Mounting Note: Bracket is not designed as ceiling mount


PSB - PWM1 - BLACK

PSB PWM1 - On-Wall Speaker

Regular price R 11,990.00

Ultra-slim, single-channel flat-panel speaker The PWM1 offers outstanding performance for its modest size. It can reproduce the most demanding musical passages or cinematic scenes with a level of detail typically found in larger speakers. Its simple 2-way design, consisting of a 1” titanium tweet Read more
