Sleek, compact, yet packing a powerful punch, the M-1 satellite speaker can be used on its own, with a subwoofer in a 2.1 system, or as the backbone of our Mini Theatre systems. From the inside out, the M-1 was conceived as a unified system. Its design has evolved in a totally integrated way, from the custom-made crossover to the two-piece clamshell cabinet.
And now, following a complete technological overhaul, including all-new drive units designed in-house, it sounds better than ever. Dispersion has increased. Imaging is pin-point accurate. Performance is now full range. In fact, the improvement is such that a single pair of M-1s could happily take on the role of your dedicated stereo speakers.
The speaker’s versatility allows it to adapt perfectly to any home environment, no matter how awkward space. You can put the M-1 on a bookshelf. Or mount it on a wall. Or position it on its own floor-length stand. It can even swivel to a horizontal position, for when you want to use one as a center channel speaker. Available in a choice of Matte Black or Matte White finishes, its clamshell cabinet is formed from just two interlockings, continuously curving sections. It all adds up to the stunning sound, whatever you are listening to.
SPECIFICATIONS
Model
M-1
Drive units
1x ø25mm (1in) metal dome high-frequency
1x ø100mm (4in) woven glass fiber cone bass/midrange
Sensitivity
85dB spl (2.83V, 1m)
Nominal impedance
8Ω (minimum 4Ω)
Crossover frequency
4kHz
Recommended amplifier power
20W – 100W into 8Ω on unclipped program
Dimensions
Height: 248mm (9.8in)
Width: 114mm (4.5in)
Depth: 162mm (6.4in)
Net weight
2.3kg (5lb) including table stand
Cabinet finishes
Matte Black
Matte White
Grille finishes
Matte Black or Matte White perforated steel to match cabinet
