Description

This large Tier 1 in-ceiling loudspeaker is designed for cost-effective installations, where product simplicity and solid acoustic performance is required. It is a two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 248 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.

Optional square grille can be used with this model.

System Format
2–Way

Channels
1

Frequency Response, Installed (-6dB)
30 Hz – 25 kHz​

Nominal Impedance
8 ohm

Minimum Impedance (20Hz to 20kHz)
6.4 Ohm @ 150 Hz

Sensitivity (2.83Vrms@1m, Installed)
88 dB

Maximum Peak SPL* (single speaker @ 1m Z-Weighted)
116 dB

Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)
75 W

Recommended Amplifier Power (RMS into 8 OHM, Music Signal)
40 – 150 W

Drive Unit Complement
1 x 9" (229 mm) C-CAM mid-bass driver
1 x 1.25" (32 mm) C-CAM tweeter

Crossover Frequency
LF/HF: 2 kHz

Mounting Depth
99 mm (37/8")

Cut-Out Hole Diameter
248 mm (93/4")

External Dimensions (Including Grille (H x W x D))
278 x 278 x 103​ mm (1015/16 x 1015/16 x 44/16)"

Weight (each)
2.5 kg (5 lb 8 oz)

Pre-Construction Bracket
CL-B

Cabinet Finish
Matt black & Orange​

Sold As
Single Unit

Price on Request
This item requires further consultation. If interested, please reach out to our team and a product specialist will reach out within the hour.

MONITORAUDIO C1L

Monitor Audio C1L Creator Series In-Ceiling Speaker (Each)

Price On Request

This large Tier 1 in-ceiling loudspeaker is a two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter. It has a cut-out dimension of 248 mm and revolutionary patented Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
Description

This large Tier 1 in-ceiling loudspeaker is designed for cost-effective installations, where product simplicity and solid acoustic performance is required. It is a two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 248 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.

Optional square grille can be used with this model.

System Format
2–Way

Channels
1

Frequency Response, Installed (-6dB)
30 Hz – 25 kHz​

Nominal Impedance
8 ohm

Minimum Impedance (20Hz to 20kHz)
6.4 Ohm @ 150 Hz

Sensitivity (2.83Vrms@1m, Installed)
88 dB

Maximum Peak SPL* (single speaker @ 1m Z-Weighted)
116 dB

Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)
75 W

Recommended Amplifier Power (RMS into 8 OHM, Music Signal)
40 – 150 W

Drive Unit Complement
1 x 9" (229 mm) C-CAM mid-bass driver
1 x 1.25" (32 mm) C-CAM tweeter

Crossover Frequency
LF/HF: 2 kHz

Mounting Depth
99 mm (37/8")

Cut-Out Hole Diameter
248 mm (93/4")

External Dimensions (Including Grille (H x W x D))
278 x 278 x 103​ mm (1015/16 x 1015/16 x 44/16)"

Weight (each)
2.5 kg (5 lb 8 oz)

Pre-Construction Bracket
CL-B

Cabinet Finish
Matt black & Orange​

Sold As
Single Unit

Price on Request
This item requires further consultation. If interested, please reach out to our team and a product specialist will reach out within the hour.
