Specifications
- Design: Ultra-Class-D™ power amplifier
- Proprietary EQ Software: Allows configuration of the amplifier for specific applications
- Interface: USB port / PBK interface for programming and optional PBK digital room correction system
-
Power Output:
- 900 watts Dynamic Peak
- 300 watts RMS
-
Amplifier Features:
- Auto-On / Off
- Soft clipping
- Electrical shorting protection
- Thermal protection
- Weight: 13.5 lbs. (6.1 kg)
- Finishes: Black
- Low Pass Filter Frequency: Variable 35 Hz – 150 Hz; Bypass Option
- Sub / Sat Phase Alignment: Variable 0° – 180°
- Inputs: RCA inputs from Sub-Out / LFE-Out of receiver, processor, or other line-level source
-
Dimensions (including rack ears for mounting in 19″ rack):
- Height: 3.5″ (8.9 cm)
- Width: 17″ (43.2 cm)
- Depth: 14.75″ (37.5 cm)
